Platform pallet Truck – P2.0-3.0S
Models
Capacity
- Robust design
- Impressive drive speeds
- Ergonomic design
- Low operating costs
- Simple maintenance
Industries
- Automotive
- Food
- Logistics
- Paper
Features
Made to perform and built to last, the robust chassis design has the added protection of a pressed bumper. The side arms, a single robust piece rotating upwards around horizontal axis, and side and rear protections, bolted to dedicated reinforcements to the frame, provide the right level of robustness, while the suspended Motor Drive Unit grants a good level of shock absorption reducing stress on the frame and the electronic components. The steel battery cover prevent damage from falling objects.
Operator cycle times are improved with performance and precision. Impressive traction speed up to 13km/h unladen and 9.7km/h laden, combined with progressive speed reduction. Switch with ease from pedestrian to ride-on mode with the foldable operator platform.
Electric Steering minimises operator fatigue to maximise productivity. The wide foldable (540 x 430mm) and fixed (516 x 456mm) platform minimises vibrations, and a low platform height simplifies access. Rear and side protection provide robust support, while easy open side arms require minimal effort to lift and lower. For an enhanced driving position, an optional adjustable tiller, which can be adjusted at the touch of a button, is available for the foldable platform version. For the fixed platform, a standard adjustable scooter control is provided. Operatives can choose from 7 driving settings, 3 pre-configured and 4 customizable, to suit their skill levels.
Cost of ownership is lowered by managing energy consumption to minimising downtime and reducing maintenance costs. Smart speed limitations enable the operator to choose the optimum productivity settings for each individual application. Increased fork visibility limits the risk of damage to both the truck and goods. Long 1000h service intervals and a 24 months warranty are provided as standard. Rapid recharging and quick-change batteries reduce downtime.
Models
Model Name | Load Capacity | Load Centre | Lift Height | Platform Height | Turning Radius | AST (wide/long) | Battery Capacity | Overall Width | Weight | Engine | Transmission |
---|---|---|---|---|---|---|---|---|---|---|---|
P3.0S platform with side protection | 3000kg | 120mm | 2902 / 2816mm | 24V / 315-500Ah(V/Ah) | 840kg | ||||||
P2.5S platform with rear protection | 2500kg | 120mm | 2998 / 2912mm | 24V / 315-500Ah(V/Ah) | 824kg | ||||||
P2.5S platform with side protection | 2500kg | 120mm | 2902 / 2816mm | 24V / 315-500Ah(V/Ah) | 840kg | ||||||
P3.0S | 3000kg | 120mm | 2492 / 2406mm | 24V / 315-500Ah(V/Ah) | 785kg | ||||||
P2.5S | 2500kg | 120mm | 2492 / 2406mm | 24V / 315-500Ah(V/Ah) | 785kg | ||||||
P2.0S platform with rear protection | 2000kg | 120mm | 2998 / 2912mm | 24V / 210 - 500Ah(V/Ah) | 807kg | ||||||
P3.0S platform with rear protection | 3000kg | 120mm | 2998 / 2912mm | 24V / 315-500Ah(V/Ah) | 824kg | ||||||
P2.0S | 2000kg | 120mm | 2421 / 2335mm | 24V / 210 - 500Ah(V/Ah) | 678kg | ||||||
P2.0S platform with side protection | 2000kg | 120mm | 2902 / 2816mm | 24V / 210 - 500Ah(V/Ah) | 823kg |
